Vortex Diamondback Tactical 6-24x50mm FFP Scope – Multiple Options

$449.99

Available Options:

Vortex Diamondback Tactical 6-24x50mm

If you think the price for the Vortex Diamondback Tactical 6-24x50mm scope is a misprint, you are dead wrong. Vortex Optics has found a way to offer every feature imaginable and pack it into one solid scope. First, the new Diamondback Tactical is equipped with a FFP reticle, which makes long range shots much more feasible. Second, the elevation and windage turrets are exposed for those shooters who would rather dial their shot instead of using holdovers. The Diamondback Tactical FFP scope includes every feature imaginable and also enters the market at a very competitive price. To make a great deal even better, Vortex Optics includes their unconditional lifetime VIP warranty with every Vortex Diamondback scope for sale.

Vortex Diamondback Tactical 6-24x50mm Features

XD Lens Elements

Extra low dispersion (XD) glass increases resolution and color fidelity, resulting in crisp, sharp images.

Fully Multi Coated Lenses

Anti-reflective coatings on all air to glass surfaces provide increased light transmission for greater clarity and low light performance.

First Focal Plane

Scale of reticle remains in proportion to the zoomed image. Constant subtensions allow accurate holdover and ranging at all magnifications.

Glass Etched Reticle

Allows for intricate reticle design. Protected between two layers of glass for optimum durability and reliability.

Tube Size

30 mm diameter provides maximized internal adjustment and strength.

Nitrogen Gas Purged

Gas purged and o-ring sealed for fog proof and waterproof performance in all conditions.

Aircraft Grade Aluminum

Constructed from a solid block of aircraft grade aluminum for strength and rigidity.

Waterproof

O-ring seals prevent moisture, dust and debris from penetrating the scope for reliable performance in all environments.

Fog proof

Nitrogen gas purging prevents internal fogging over a wide range of temperatures.

Shock proof

Rugged construction withstands recoil and impact.

Hard Anodized Finish

Highly durable low glare matte finish helps camouflage the shooter’s position.

Precision Glide Erector System

Uses premium components in the zoom lens mechanism to ensure smooth magnification changes under the harshest conditions.

Exposed Tactical Turrets

The Diamondback Tactical scopes feature tactical windage and elevation turrets with Zero Reset making adjustments back to zero easy and quick.

Precision Glide Erector System

Uses premium components in the zoom lens mechanism to ensure smooth magnification changes under the harshest conditions.

Precision force Spring System

Uses premium components in the erector spring system to ensure maximum repeatability and ease of adjustment.

Fast Focus Eyepiece

Allows quick and easy reticle focusing.

Magnification Rib

The raised rib on the magnification ring facilitates fast magnification changes in the heat of action.

Reticle Manual

Product Manual

Parts Diagram


EBR-2C (MOA)

Hash-marked ranging reticle using MOA based subtension lines for ranging, holdover, and windage corrections. Letters refer to reticle subtensions listed in chart below.

Subtension detail for Diamondback Tactical 6-24×50 FFP riflescope with EBR-2C MOA reticle.

EBR-2C (MRAD)

Hash-marked ranging reticle using MRAD based subtension lines for ranging, holdover, and windage corrections. Letters refer to reticle subtensions listed in chart below.

Subtension detail for Diamondback Tactical 6-24×50 FFP riflescope with EBR-2C MRAD reticle.


Specifications

Magnification 6-24x
Objective Lens Diameter 50 mm
Eye Relief 3.9 in
Field of View 18-4.5 ft @ 100 yrds
Tube Size 30 mm
Turret Style Tall Exposed Tacticle
Adjustment Graduation 0.1 MRAD
Travel per Rotation 6 MRAD
Max Elevation Adjustment 19 MRAD
Max Windage Adjustment 19 MRAD
Parallax Setting 10 yards to Infinity
Length 14.5 in
Weight 24.6 oz


VIP Warranty

VIP stands for a Very Important Promise to you, our customer. We will repair or replace your Vortex product in the event it becomes damaged or defective—at no charge to you. If we cannot repair your product, we will replace it with a product in perfect working order of equal or better physical condition. You see, it doesn’t matter how it happened, whose fault it was, or where you purchased it. You can count on the VIP Warranty for all Vortex Optics riflescopesprism scopesred dotsrangefindersbinocularsspotting scopestripods, and monoculars.
