Trijicon VCOG 1-8×28 SCO Scope
The Trijicon VCOG 1-8×28 SCO Scope was designed to be highly rugged and reliable. It features an aircraft grade 7075-T6 aluminum housing making it nearly indestructible. Superior glass provides exceptional clarity and color with zero distortion. The universal segmented circle / MRAD crosshair dot with wind holds reticle is designed for multi platform use, accommodating multiple calibers, ammunition weights, and barrel lengths. The first focal plane reticle allows sub tensions and drops to remain true at any magnification, allowing the shooter to quickly and accurately apply the correct hold.
With ruggedized electronics, the LED reticle is robust enough for any application. Powered by a lithium AA battery (provided), the 1-8×28 VCOG offers a battery life of 633 hours at setting 6. Choose from 11 user selectable brightness settings, 2 night vision settings, 8 day settings, and a 1 super bright setting. An integrated dial fin allows easy rotation through the magnification range, and a near constant eye relief means no head or stock position adjustments are needed. Waterproof to 20 meters (66 ft.).
Trijicon VCOG 1-8×28 SCO Scope Features
Features |
||||||
Alaska to Africa Temperature Tested | To ensure each family of riflescopes is ready for whatever the users put them through, Trijicon perform “Alaska to Africa” temperature shock tests with temps from -20°F to 140°F | |||||
Solid Zero Tested | Their riflescopes are designed to hold their zero giving you the precision you need. Every model is subjected to 5,000 consecutive rounds, confirming no reticle shift has occurred. | |||||
Drop Tested | Trijicon doesn’t believe every drop should be followed by a warranty claim. Each riflescope design is put through a drop to check for durability. | |||||
Shock and Vibration Tested | All riflescope models are tested to withstand recoil and vibrational stresses without malfunction, so it can take a beating before, during, and after use. | |||||
Immersion Tested | All models are immersion tested, and every riflescope is dry nitrogen filled to eliminate internal fogging. |
Superior Quality Glass
Multi coated lenses provide superior clarity and light gathering capabilities with zero distortion
Virtually Indestructible
Tested to MIL-STD-810G, a series of tests approved by the U.S. Department of Defense to simulate conditions in the field.
Rapid Target Acquisition
First focal plane reticle allows user to rapidly acquire target and apply correct hold throughout magnification range.
Bright, Crisp Illumination
Brilliantly illuminated reticle is powered by a single AA battery.
Quick, Accurate Ranging Reticles
1-6×24 offers BDC or Universal MRAD and MOA reticles; 1-8×28 offers Universal MRAD and MOA reticles
Easy to Set Adjusters
Allows user to easily adjust windage and elevation.
No Rings Needed
The need for conventional ring mounts is eliminated with the integrated mounting adapter that provides quick and easy mounting to any rail system. Compatible with many rails in the marketplace designed to fit the Trijicon ACOG.
Adjustable Brightness Settings
Multiple brightness settings with an “off” between each setting. 1-8×28 models feature 11 brightness settings, 1-6×24 models feature 6 brightness settings.
Quick Magnification Adjustments
Integrated dial fin allows easy rotation through magnification settings.
Included
Larue Tactical LT799 Mount
Tenebraex Flip Caps
Soft Carrying Case
Lithium AA Battery
LENSPEN (TA56)
Trijicon Logo Sticker (PR15)
Manual
Warranty Card
Specifications |
||||||
Length x Width x Height | 10.93 in x 2.91 in x 2.8 in
(277.62mm x 73.91mm x 71.12mm) |
|||||
Weight | 32 oz.
(907.18g) |
|||||
Magnification | 1-8x | |||||
Objective Size | 28mm | |||||
Reticle Pattern | Segmented Circle / Crosshair with Wind Holds | |||||
Day Reticle Color | Red | |||||
Night Reticle Color | Red | |||||
Focal Plane | First | |||||
Bindon Aiming Concept (BAC) | Yes | |||||
Illumination Source | LED | |||||
Illumination Settings | 11 Total Settings: 2 Night Vision, 8 Day, and 1 Super-Bright Setting | |||||
Power Source | AA Lithium or Alkaline Battery | |||||
Battery Life | 633 hours (26.4 days) at setting 6 | |||||
Adjustment | 0.1 MRAD per click | |||||
Adjustment Range | 35 MRAD | |||||
Eye Relief | 4 in.
(101.6mm) |
|||||
Exit Pupil | 0.41 in. – 0.14 in.
(10.41mm – 3.56mm) |
|||||
Field of View (degrees) | 20° – 2.5° | |||||
Field of View (feet) | 109.2 ft. – 13.1 ft. @ 100 yds.
(36.4 – 4.37m @ 100m) |
|||||
Mount | Larue Tactical LT799 Mount | |||||
Housing Material | 7075-T6 forged aluminum | |||||
Finish | Matte Black | |||||
Submersion Depth | 66 ft.
(20m) |
|||||
Operating Temperature | -25F to 140F
(-31.67c to 60c) |
