Trijicon ACOG ECOS 4x32mm
The Trijicon ACOG ECOS is the ultimate sight for both Close Quarter Battle (CQB) situations and longer distance shooting where accuracy and pinpoint bullet placement are required. This dual sighting system gives the shooter a distinct tactical advantage with the option of either the Trijicon ACOG or RMR Type 2 sight. With the quick target acquisition of the RMR Type 2 Sight or the precise aiming capabilities provided by the magnified 4 power Trijicon ACOG the shooter has the ability to select the proper aiming solution for the situation at hand truly the best of both worlds. No tools are needed for windage and elevation adjustments because the ECOS also features external windage and elevation adjusters, making it waterproof up to 11m without caps.
Trijicon ACOG ECOS Features
Always On, Always Ready
Most ACOG models are battery free, featuring a tritium and fiber optic illuminated reticle that automatically adjusts the brightness based on available light.
Take Control
Several ACOG models are designed with a user adjustable brightness setting powered by a single AA battery. The 3.5×35 LED and 4×32 LED models both offer six adjustable brightness settings.
Rugged, Reliable Housing Design
Fixed-power design allows for minimal moving parts to create a nearly indestructible sighting system.
Both Eyes Open Design
Both eyes open shooting using The Bindon Aiming Concept (BAC) allows for improved situational awareness.
Outstanding Clarity
The quality of the glass and multi coated lenses maximize light gathering capabilities and clear field of view with zero distortion.
Exact Target Distances & Holds
Most ACOG models feature a bullet drop compensating and target ranging reticle for decisive aiming.
Combat Proven
No other magnified optic has been used more in combat than the ACOG.
Shock Resistant
Proven to withstand recoil from a .22LR to a .50BMG and everything in between. Easily passes U.S. Military drop test requirements.
Waterproof
Exceptional waterproof performance that exceeds military standards. Dry nitrogen filled to eliminate fogging. This optic is tested to withstand and perform in extreme cold and heat with dry nitrogen filled housing that mitigates fogging.
Specifications |
||||||
Weight | 15 oz. (425.24g) | |||||
Magnification | 4x | |||||
Objective Size | 32mm | |||||
Reticle Pattern | Crosshair | |||||
Day Reticle Color | Red or Green | |||||
Night Reticle Color | Red or Green | |||||
Bullet Drop Compensating (BDC) | Yes | |||||
Caliber | 0.223 | |||||
Bindon Aiming Concept (BAC) | Yes | |||||
ACOG Illumination Source | Fiber Optics & Tritium | |||||
RMR Power Source | CR2032 | |||||
Eye Relief | 1.5 in. (38.1mm) | |||||
Exit Pupil | 0.32 in. (8.13mm) | |||||
Field of View (degrees) | 7° | |||||
Field of View (feet) | 36.8 ft. @ 100 yds. (12.27m @ 100m) | |||||
Mount | Quick Release | |||||
Housing Material | Forged Aluminum | |||||
Finish | Flat Dark Earth (FDE) |
