Primary Arms SLx 1-10x28mm SFP Scope
The Primary Arms SLx 1-10x28mm is a second focal plane scope that was built on Primary Arms’ reputation of innovation, reliability and value. Like all SLx optics, the 1-10x28mm undergoes rigorous field testing during development to best serve you in any environment.
The scope takes what is popular about low power variable optics and steps it up a notch to a larger magnification range without making sacrifices common with more traditional 10x optics. Primary Arms first true 1-10x LPVO boasts a generous 3.2-3.5 inches of eye relief allowing you to easily set this scope up on your rifle of choice and still features a great field of view throughout the magnification range. With the addition of an integrated magnification lever, you can quickly and easily go from a true 1x sight picture all the way up to 10x magnification for those longer distance precision shots or simply for better target identification.
This is truly a versatile optic that can do it all from close quarters to long range while still only weighing 19.1 ounces at 10.5 inches long. Just like Primary Arms other optics, this scope is protected by the Primary Arms Lifetime Warranty.
Primary Arms SLx 1-10x28mm Features
Second focal plane ACSS Griffin M10S or ACSS Raptor M10S reticle
M10S Reticle optimized for second focal plane design
Integrated magnification lever
11 Illumination settings with 2 NV settings
Daylight visible illumination
Partial illuminated horseshoe and chevron aiming point
1-10x magnification range
28mm objective lens
3.2 – 3.5 inches of eye relief
34mm Tube diameter
High strength one piece 6061-T6 aluminum body
Black hardcoat anodized
Only 10.5″ long and weighs 19.1 oz.
Tested and proven for durability with extensive live fire testing
Backed by an industry leading Lifetime Warranty
ACSS Griffin MIL M10-S Reticle
The ACSS Griffin MIL M10-S is a SFP reticle that is purpose made for optics with a 1-10x magnification range. In close quarters, the ACSS Griffin MIL M10-S offers a bold horseshoe with a chevron tip. For long range precision, users can leverage the full functionality of their ACSS reticle. The ACSS Griffin MIL M10-S integrates an intuitive MIL grid and both vertical and horizontal ranging stadia for quick range estimation and target engagement. Check out the manual below for a deep dive into all the functionality of this reticle.
ACSS Raptor 5.56 M10-S Reticle
The ACSS Raptor 5.56 M10-S is a SFP reticle that is purpose made for optics with a 1-10x magnification range. In close quarters, the ACSS Raptor 5.56 M10-S offers a bold center chevron and outlying horseshoe for fast target acquisition. For long range precision, users can leverage the full functionality of their ACSS ballistic drop compensating reticle, including vertical and horizontal ranging, multi value wind holds, moving target leads, and intuitive ballistic holdovers to 800 yards. Check out the manual below for a deep dive into all the functionality of this reticle.
Specifications |
||||||
Battery Type | CR2032 3V Lithium Coin | |||||
Click Value | .5 MOA | |||||
Exit Pupil Diameter | Low: 9mm
High: 2.8mm |
|||||
Eye Relief | Low: 3.2 in
High: 3.5 in |
|||||
Field View 100 | Low: 110 ft
High: 10 ft |
|||||
Focal Plane | Second Focal Plane | |||||
Illuminated | Partial Illumination | |||||
Length | 10.5 in. | |||||
Magnification | 1X – 10X | |||||
Night Vision Compatible | Night Vision Compatible | |||||
Objective Diameter | 28mm | |||||
Optic Series | SLx | |||||
Reticle | ACSS Griffin M10S
ACSS Raptor M10S |
|||||
Reticle Color | Red | |||||
Reticle Type | MRAD (ACSS Griffin M10S)
BDC (ACSS Raptor M10S) |
|||||
Total Elevation Adjustment | 40 MOA | |||||
Total Windage Adjustment | 40 MOA | |||||
Tube Diameter | 34mm | |||||
Weight | 19.1 oz. |
