Meprolight Tru-Vision Red Dot Sight
The Meprolight Tru-Vision is a red dot sight that offers advanced features such as small dimensions, lightweight, and a built in light sensor.
The Tru-Vsion electro-optical MIL-SPEC red dot sight is shockproof, waterproof, and durable. Its short-length, compact, and lightweight design addresses the need for co-mounting multiple tactical devices (magnifiers, laser pointers, etc.) on your Picatinny rail. In addition, it is compatible with the Mepro MX3F/T magnifier and other popular models to facilitate engaging targets at intermediate shooting distances. Energy efficient, it provides thousands of operating hours from a single “CR123” standard battery.
The Meprolight Tru-Vision also features an automatic brightness control system that enables clear visibility of the red dot in any lighting condition. In addition, if the user manually controls the reticle brightness level, there are 16 brightness settings (12 daytime, 4 nighttime (NVG/NOD)), allowing the user to adjust to any lighting condition they may encounter.
The large non-reflective display window (1.14″ x 0.78″) and clearly defined 2 MOA red dot reticle ensure rapid target acquisition with both eyes open and unlimited field of view while remaining parallax free. Zeroing elevation and windage adjustment screws move the reticle by 0.5 MOA per click.
In addition, the sight has an integrated sleep mode (after 30 minutes of no movement and when no button is pressed) and an automatic power-off mode of 4 or 8 hours (user selectable) when no button is pressed/no movement is detected. It is equipped with a low battery indicator, a light sensor, a manual, and a soft cover in the factory packaging.
Meprolight Tru-Vision Features
Automatic brightness control (built-in light sensor)
Built-in motion sensor
Automatic sleep and wake up modes
Compatible with NVG & with magnifier scope
Compact, lightweight ergonomic design
Continuous Operation: 2 years
Non-reflective large display optic window
Specifications |
||||||
Weight | < 285 gr. | |||||
Dimensions (L x W x H) | < 73 x 56 x 68 mm | |||||
Display Window Dimensions | 25 x 20 mm | |||||
Aiming point diameter | 2.0 MOA | |||||
Reticle Pattern | Dot | |||||
Reticle Color | Red | |||||
Click Size | 0.5 MOA (0.14 mRad) | |||||
Brightness levels | 12 Day + 4 Night + Automatic Adjustment | |||||
Power Supply | 1x CR123 Battery | |||||
Weapon Mount | Picatinny Rail Quick release (Mil-STD 1913) | |||||
Environmental | MIL-STD-810 |
