Leica Calonox View
The Leica Calonox View is the perfect hunting companion and lets spot game up to 3,000 meters away. This thermal imaging monocular is a go to choice for a nighttime hunting set up to ensure target identification. The Calonox View is an indispensable hunting companion that offers superior image quality with Leica Image Optimization (LIO). LIO improves the image with special algorithms, thus achieving particularly detailed color gradations, excellent contrast, and high detail resolution. The outstanding recognition range of the Calonox View is based on a high end vanadium oxide (VOx) sensor with 640 x 512 pixels and 12 µm pixel size with excellent temperature resolution. It features 4 color modes, Red Hot, White Hot, Black Hot and Rainbow. All color modes allow for high contrast detailed recognition.
Leica Calonox View Features
Image quality
With the Calonox thermal cameras, Leica continues its long, successful track record in digital image optimization. Leica’s own image processing (Leica Image Optimization – LIO) improves the image with special algorithms, thus achieving particularly detailed color gradations, excellent contrast, and high detail resolution. The outstanding recognition range of the Leica Calonox View is based on a high end vanadium oxide (VOx) sensor with 640 x 512 pixels and 12 µm pixel size with excellent temperature resolution.
Photo/Video Function
The Leica Calonox View has 16 GB internal memory for recording special observations as photos or videos. Using the Calonox View App, the stored images can be transferred to a smartphone via WLAN, or to a computer via cable. Live view observations are also possible via cell phone.
Range
See more, identify game safely: With a defined target size of 1.7 x 0.5 m, the Leica Calonox View can detect targets up to a distance of 3,000 meters, recognize targets up to 1,000 m, and precisely identify them up to 500 m.
Zoom
Ideal for close up observations, the 42mm objective in combination with the 2.5x basic optical magnification provides a large field of view and the best overview. The digital zoom can be set to a magnification of up to 10x, so that no details remain hidden, even at great distances.
Color Modes
The four color modes White Hot, Black Hot, Red Hot, and Rainbow provide practical display variations and greater, high-contrast detail recognition.
Calonox View App
Quick and easy: With the Calonox View App, photos or videos stored on the camera can be transferred to the smartphone via WLAN. In addition, the live view function makes it possible to observe the scenery on your cell phone screen. With a simple click, you can switch the display from day mode to night mode.
Calibration
With the three integrated calibration modes Auto (A), Manual (M), and Background (B), you can restore, refresh, and enhance the image on the display. In modes A and M, shutter calibration is initiated automatically or, if you wish, manually at the touch of a button. Background calibration with a covered objective lens is particularly efficient and achieves the best results.
Design & Operation
The shapely product design in the well known Leica style is geared towards the user’s hunting needs. Its cylindrical shape and easy operability integrate perfectly into the hunter’s equipment. The user friendly, intuitive three button menu offers streamlined navigation, which enables easy and quick handling even when wearing gloves.
Display & Rechargeable Battery
The powerful HD display with 1280 x 960 pixels enables comfortable observation and reliable identification when stalking or when shooting from blinds. The permanently installed rechargeable battery with approx. 5 hours of power is particularly well protected against cold and moisture. And charging is possible during operation, e.g. by using a powerbank.
Leica Calonox View – What’s included
Calonox View
Cordura Case
Charging Cable
Carry Strap
Quick Start Guide
Lens Cleaning Cloth
Certificate
Specifications |
||||||
| Sensor Type | VOx | |||||
| Sensor Size | 640 x 512 pixels | |||||
| Pixel Size | 12 μm | |||||
| Screen Type | LCOS | |||||
| Screen Diagonal | 0.4” | |||||
| Screen Resolution | 1280 x 960 pixels | |||||
| Image Repetition Frequency | 50 Hz | |||||
| Lens Focal Length | 42 mm | |||||
| Optical Basic Magnification | 2.5x | |||||
| Digital Zoom | 1x/2x/3x/4x | |||||
| Field of View | 10.5 x 8.4°
(18.3 m x 14.6 m/100 m) |
|||||
| Diopter Adjustment | ±5 dpt | |||||
| Range/Resolution | 1.7 m x 0.5 m
(66.9 inch x 20.0 inch) |
|||||
| Detection Range/Resolution | 3000 m/2 pixels
(3281 yrd/2 pixels) |
|||||
| Recognition Range/Resolution | 1000 m/6 pixels
(1094 yrd/6 pixels) |
|||||
| Identification Range/Resolution | 500 m/12 pixels
(547 yrd/12 pixels) |
|||||
| Video Output | PAL | |||||
| Video Recording | yes | |||||
| Video/Picture Resolution | 768 x 576 pixels | |||||
| Cable Socket | USB-C | |||||
| Wireless Connection | Wi-Fi (2.4 GHz) | |||||
| Internal Memory | 16 GB | |||||
| Protection Type | IPX4 | |||||
| Operating Temperature | -10 to +50 °C
(-4°F to 122°F) |
|||||
| Operating Temperature (Charge Battery) | +10 to +30 °C
(50°F to 86°F) |
|||||
| Battery Life | approx. 4 – 5 h | |||||
| Tripod Thread | A ¼ DIN 4503 (¼”), M5 standard thread | |||||
| Dimensions (WxH) | 170 x 65 mm
(6.7 x 2.6 inch) |
|||||
| Weight (With battery) | 685 g
(24.2 oz) |
|||||
