AGM ObservIR LRF 35-384 Thermal & Digital Day/Night Vision Binocular
The AGM ObservIR LRF 35-384 Thermal & Digital Day/Night Vision binocular is some of the most technologically advanced and feature-packed optics in the world. The primary engine behind these binocular lies within the main thermal viewing channel, with its high-sensitivity 12 micron detector. Unlike other thermal binoculars on the market, the ObservIR LRF also come outfitted with a digital day/night channel as well, which is great for aiding in recognition of targets detected by the thermal channel. The built-in 1,000m laser rangefinder simply takes the ObservIR to another level, and this is without even mentioning its 64GB of internal memory and Wi-Fi compatibility.
The ObservIR LRF binocular also come packed with numerous software improvements, and many features that have become commonplace within the AGM thermal product assortment: high-sensitivity thermal detector, 35 mm objective lens with a 1.0 aperture, 3840×2160 ultra-low light CMOS sensor, various viewing modes, multiple color palettes, picture-in-picture mode, built-in laser rangefinder, GPS module, long-range IR illuminator, up to 8 hours of battery life on removable, rechargeable 18650 batteries,
USB Type-C port for external power capabilities, IP67 waterproof rating. The package includes four 18650 batteries, wrist strap and charger.
AGM ObservIR LRF Features
Dual-spectrum thermal and digital day/night system
12μm high-sensitivity thermal sensor
384×288 thermal resolution
4x – 20x thermal magnification
Digital image processing technology
Ultra-low illumination optical channel
3840×2160 optical resolution
Built-in IR illuminator
Eye-safe 1,000 m laser rangefinder
1920×1080 resolution, 0.49-inch OLED display
Digital Magnetic Compass
Built-in GPS module
Video/audio recording and snapshot capture
Built-in 64 GB EMMC storage
Wi-Fi hotspot
Standby mode
8-hour continuous operation on a single charge
Auto screen-off function to saving energy
External power supply capability
Rugged housing with rubber overmolding
Waterproof and dustproof
Specifications |
||||||
| Interpupillary Distance | 60 mm to 74 mm | |||||
| Safety Class for Laser | Class 1 | |||||
| Palettes | Black Hot, White Hot, Red Hot, Fusion | |||||
| Dimensions | 221×142×71 mm (8.7×5.6×2.8 in) | |||||
| Infrared Illuminator | Built-in 850nm Smart IR.Power and beam angle adjustment. | |||||
| Distance Measurement | Laser Rangefinder: up to 1,000 m, ±1 m accuracy | |||||
| Scene Mode | Jungle, Recognition | |||||
| Video Recording | Yes | |||||
| Audio Recording | Yes | |||||
| Magnification | Thermal Channel – 4.0x – 20x / Optical Channel – 5.5x – 22x | |||||
| Detector type | Thermal Detector – 12μm VOx Uncooled Focal Plane Array / Digital Sensor – 3840×2160, 1/88” Progressive Scan CMOS | |||||
| FFC (Flat Field Correction) | Auto, Manual, External Correction | |||||
| Highest Temperature Spot Tracking | Yes | |||||
| Standby Mode | Yes | |||||
| Refresh rate | 50 Hz | |||||
| Resolution | 384 × 288 | |||||
| Laser Wavelength | 905 nm | |||||
| Detection Range (6′ object) | 1,800 m | |||||
| Snapshot | Yes | |||||
| Lens system | Thermal Channel – 35 mm; F1.0 / Optical Channel – 60 mm, F2.2 | |||||
| NETD | Less than 15 mK (25°C, F#=1.0) | |||||
| Field of view (H × X) | Thermal Channel – 7.5° × 5.7° / Optical Channel – 6.9° × 4.1° | |||||
| Diopter adjustment range | -5 to +3 | |||||
| Monitor | 1920×1080, 0.49 inch, OLED, 50 FPS | |||||
| Display | Day, Night, Auto | |||||
| Storage | 64 GB EMMC | |||||
| Battery Type | Two 18650 rechargeable battery (removable) | |||||
| Wi-Fi | Yes | |||||
| Battery Life (Operating) | Up to 8 hours continuous running (@25°C, WiFi, IR and LRF off) | |||||
| Power supply | 5 VDC/2 A, USB Type-C interface. Supports external power supply. | |||||
| Operating Temperature Range | -20°C to 55°C (-4°F to 131°F) | |||||
| Weight | 0.91 kg (2.01 Ib) | |||||
| Protection Level | IP67 (Waterproof) | |||||
Export Restrictions
Product shown herein is subject to US export regulations and may require a license prior to export. Any diversion contrary to US Government regulations is prohibited.
